In .NET 7 (previewed in .NET 6) a series of new interfaces were introduced to make work with mathematical operations easier.
.NET has had generics almost forever allowing you to write algorithms that work with many different types, but this hasn’t been possible for basic maths until this was introduced.
The main reason this has been done now is for machine learning and AI implementations where the classic computing tradeoff of speed vs. space appears - if you’re dealing with very large arrays of numbers, maybe you want to switch from a 64 bit double to 32 bit float (or even the newly introduced 16 bit half).
There is another reason to use the interfaces though - perhaps you want a completely different implementation of the basic mathematical operations. One example would be fixed-point arithmetic instead of floating-point arithmetic.
The biggest reason to do this is because floating-point arithmetic is not, in practice, deterministic.
More about floating-point arithmetic determinism
This is a subtle topic. Any specific IEE 754 floating point operation is deterministic for the same inputs. But those inputs include various settings that might change unexpectedly, and things like reordering of operations will give you different results due to rounding.
And it is even worse in .NET (ironically) because of its portable nature. Your code could be JIT compiled completely out of your control on many different processor architectures.
That last one is fairly recent (it targets .NET 6) and is MIT licensed, so I decided to see if I could modify it to support the generic math interfaces.
It takes the F32 and F64 types from FixPointCS and implements the following interfaces:
INumber
IBinaryNumber
ISignedNumber
IRootFunctions
ITrigonometricFunction
Most of the work is forwarding to the existing implementations. Some of the things that I had to actually write code for:
Formatting and parsing
There are a bunch of methods relating to converting to and from strings. My implementation uses double as an intermediate type. I guess these have the chance to not be deterministic but for the things I’d use it for it would not matter.
TryConvertFrom… and TryConvertTo…
These methods are used to convert between these types and others. They come in three versions: Checked, Truncating and Saturating. I have currently implemented all three to do the same thing.
— This upcoming video may not be available to view yet.
One final feature my expanded Elo rating needs (or at least the last I can think of) is the ability to deal with ad hoc teams.
By “ad hoc teams”, I mean teams of individual players with their own ratings that are on the same team for a specific game, but don’t generally stay as a team (established teams that always play together should be treated as their own “players” with their own rating).
This is not a common requirement, but the specific use case I had was an office ping pong table. Some times people would play singles and some times they would play doubles, but with no really established teams.
Necessary features
Firstly, the two key ratings operations need to work:
Estimate the result of an unplayed game
Updating ratings after an actual result
And all the existing features should be supported:
Two or more teams
Unfair games
Ties
Additionally, it should support teams of arbitrary (and mixed) sizes, including teams of size one. This brings us to one of our first less-obvious requirements - since this is expanding an existing system, it should be compatible with the existing system where it overlaps. So the following additional requirement makes sense:
Teams of one should give the same result as just using individuals
Simple solution
Just like with unfair games in which an adjusted rating is calculated first, and then used in the rest of the algorithm, and adjusted rating should be calculated for a team. This would trivially allow all the existing features to just work.
The most obvious way to calculate such a rating would be a simple arithmetic mean of all the players. This would definitely support our key requirement, but would it produce meaningful results?
At this point I think simplicity has to win out over sophistication. The most general solution would allow players to be weighted on each team (perhaps different roles in a team have different impacts on the result) but I think those situations are more likely to be handled with a per team rating.
— This upcoming video may not be available to view yet.
In my previous post, I described an extension to Elo that could handle multiple players. The next restriction to overcome is that Elo assumed players of equal skill have an equal chance of winning.
In most games, players don’t actually have an equal chance of winning a single game. Chess overcomes this by having a match consist of several individual games with players switching who goes first. This is a good solution for two player games but gets awkward for multiplayer games. It is also inconvenient if having a multi-game match is undesirable for any reason.
Adjusted rating
Elo is fundamentally designed to handle players of different skill levels and produce a probability of them winning. The approach is therefore to determine an adjusted rating for someone such that the probability of winning is as desired.
The formula to work out an Elo expected score is:
In our case we have an expected score (the win probability) and want to work out a rating difference, so we can just rearrange to get:
We then subtract this adjustment from the player’s actual rating to get their effective rating to use in the rest of the Elo calculations.
The reason we subtract it is that for players A and B, the rating difference is calculated as RB - RA which is the opposite way round to what we want.
Here are the rating adjustments for some sample win probabilities:
Win probability
Rating adjustment
0.01
-798
0.10
-382
0.25
-191
0.49
-7
0.50
0
0.51
+7
0.75
+191
0.90
+382
0.99
+798
If you try to calculate the adjustment for a win probability of 0 or 1, you get -∞ and +∞ respectively.
This means, for example, if you beat someone of an equal rating at a game you only have a 10% chance of winning, it’s the same as beating someone rated 382 points higher at a fair game.
Putting it all together
After explaining the theory of how to expand an Elo rating to support all the variations in Tic-tac-toe Collection, it’s time to put it into practice.
While writing this I’ve also been working on an implementation.
As well as adding it to Tic-tac-toe Collection, I’m planning on creating some kind of site and/or app just to work out Elo ratings for various results (and hopefully even to maintain ratings for players in any kind of competition you might want to run).
— This upcoming video may not be available to view yet.
One of the features I have planned for Tic-tac-toe Collection is a player rating system.
One such common rating system is the Elo rating system, most famously used in chess. There is a lot of discussion about how good it is, but for my purposes it seems fine - at least as a starting point.
There are two fundamental restrictions on Elo that I would have to overcome though:
It is limited to two players.
It assumes each player has an equal chance of winning if they have equal skill.
Elo
First an introduction into how Elo rating works. There are two parts:
Given two player ratings, calculate an expected result.
The expected result is essentially the chance of winning, given as a decimal between 0 and 1, in which 0 represents a guaranteed loss and 1 a guaranteed win.
Given a player rating, an expected result, and an actual result, calculate how much the rating should change.
If you do better than expected then your score will go up. If you do worse then your score will go down. With a bigger difference there will be a bigger change.
In SME, players are ordered by performance, and then a simulated match is played between pairs of consecutive players, with the players’ ratings updated using the normal Elo method for two players.
This is certainly acceptable, and Tom includes some tests to show it works well. One oddity is if you get a victory over someone with a much higher rating than you, but also beat them by more than one place, you essentially don’t get the benefit for it. For example, consider the following result:
Position
Player
Initial rating
vs player above
vs player below
Total
1st
A
1000
+24
+24
2nd
B
1200
−24
+27
+3
3rd
C
1500
−27
−27
Here, Player A with a rating of 1000 has beaten Player C with a rating of 1500, but essentially hasn’t gotten the credit for it.
My unnamed Elo
My solution is to conceptually run the algorithm on every pair of players (in this case there would be A v B, B v C and A v C). There is a straightforward optimization so that the estimating part of the operation does not directly depend on the other players, just the difference between a single player’s expected and actual scores. So the algorithm is actually:
Calculate the expected scores for each pair of players.
Sum the expected score for each player.
Divide each score by the number of players to normalize back to the range 0 to 1.
Calculate the rating change for each player using their actual score and the combined expected score.
The details
With the same data as above, the results are as follows:
Player
Initial rating
Expected score
A
1000
0.097
B
1200
0.304
C
1500
0.599
Which is made up of the following score pairs:
Pair
A
B
C
A v B
0.24
0.26
B v C
0.15
0.85
A v C
0.05
0.95
This results in rating changes of:
Position
Player
Initial rating
Change
1st
A
1000
+29
2nd
B
1200
−9
3rd
C
1500
−19
Player A has gained more which is good. That was basically the goal of the change.
Player B has now changed a small gain into a moderate loss. That’s a little odd and probably not desired, after all the victory against C should be more significant than the loss against A
Player C has changed a big loss into a slightly smaller (but still big) loss. After some thought, that is probably reasonable. Although C is expected to win just having more players should generally reduce your expectation of winning and therefore how much you are penalized for failing.
Improvements
So why did these results happen? It might be better to look at a table also including expected and actual results, which reveals a choice that has to be made that I have not yet mentioned:
Position
Player
Initial rating
Expected score
Actual score
Change
1st
A
1000
0.097
1
+29
2nd
B
1200
0.304
0
−9
3rd
C
1500
0.599
0
−19
Notice the actual scores used. Player A has a score of 1 indicating a win. Players B and C have a score of 0, which indicates a loss, but an equal loss.
If we instead use different values for the actual score we get a more sensible result
Position
Player
Initial rating
Actual score
Change
1st
A
1000
0.67
+18
2nd
B
1200
0.33
+1
3rd
C
1500
0
−19
In this case, the “actual score” for a player placed Nth out of C is:
Explain this formula
This formula is conceptually simple, but a bit opaque when simplified.
Think of it as each player getting a number of shares of the total score. The person in last gets 0 shares, the person second from last gets 1 share, then next player gets 2 shares, and so on. The person in first place gets C−1 shares.
That means each player gets N shares and the total number of shares is equal to the C−1th Triangular number.
The formula for a triangular number is:
Substituting C-1:
This simplifies to:
Therefore each player gets:
which simplifies to:
Handling ties
To be as general as possible (and because it actually happens in some of my multiplayer Tic-tac-toe variants) we need to handle arbitrary ties.
The simplest way is to evenly distribute the score to all the players that are tied. So if the top two players in a three-player game tie, their scores of 0.67 and 0.33 are summed and split between them (0.5 each).
As a more complex example, consider:
Position
“Raw” score
Actual score
1st
0.286
0.262
1st
0.238
0.262
3rd
0.190
0.143
3rd
0.143
0.143
3rd
0.095
0.143
6th
0.048
0.048
7th
0
0
Final thoughts
I’ve addressed the first restriction of Elo, only supporting two players. As for unfair games, that will have to wait as this post is long enough as it is.
— This upcoming video may not be available to view yet.
This was a question that came up recently, and the answer is interesting enough I decided to step through the process of working it out.
A good year
There are seven days in the week. If the year had a number of days in it that was divisible by seven (say 364), then the answer would be easy: every year and every date would fall on the same day every year.
This would have some nice properties. Some of the more complicated holidays that need to happen on certain days would get simpler, and the poem about what kind of person you are based on the day of your birth would be more poignant since your birthday would be the same each year.
A normal year
But alas, the number of days in the year is not divisible by seven, and we have to suffer with a different calendar each year. But there is good news, there are only seven possible calendars - one starting on each day of the week.
With 365 days in the year, we would have the following possible calendars:
Monday 1st January, Tuesday 2nd January … Monday 31st December
Tuesday 1st January, Wednesday 2nd January … Tuesday 31st December
Wednesday 1st January, Thursday 2nd January … Wednesday 31st December
Thursday 1st January, Friday 2nd January … Thursday 31st December
Friday 1st January, Saturday 2nd January … Friday 31st December
Saturday 1st January, Sunday 2nd January … Saturday 31st December
Sunday 1st January, Monday 2nd January … Sunday 31st December
After we have cycled through those calendars, the pattern starts again. Hooray.
Leap years
Of course it is not that simple. Every four years we have a year with an extra day in it, throwing everything off. And to fix it we will need Maths.
We have a cycle of seven starting days, overlaid with a four year cycle of leap years. To determine when the large cycle repeats we need to calculate the least common multiple of four and seven. Since four and seven are coprime (they have no common divisors), their least common multiple is their product.
4 × 7 = 28
So you will be able to reuse your calendar every 28 years.
Knowing when the whole cycle repeats give you an answer to when you can reuse your calendar, but not necessarily the best answer. Applying a bit of logical reasoning, you can work out that there are only 14 possible calendars: one for each day of the week in a leap year, and one for each day of the week in a common year.
A non-leap year is also called a common year.
Sadly, at this point clever maths is probably less illustrative than a brute force approach. Since we know the cycle is only 28 items long, the force is not that brutish…
I shall name the possible calendars with a number indicating the day of the week they start on (1 for Monday), and a letter L or C, indicating a leap year or common year respectively.
Lets start with a common year:
C1
As you may have noticed from earlier, the year after a common year begins with the next day.
C1 C2
We can continue the pattern up to the first leap year, since leapyness does not affect how a year starts.
C1 C2 C3 L4
But what next? A leap year has an extra day, so instead of going up by one, we go up by two.
C1 C2 C3 L4 C6
We are now ready to complete the pattern (remembering after 7, we go back to 1)
The cycle is 28 years long, and there are 14 possible calendars so you might naïvely think each one appears twice, but that isn’t the case. The leap years appear once each, and the common years appears three times each.
This means for leap years, our guess at waiting 28 years to reuse a calendar is correct. For common years, you can reuse your calendar, on average every 9⅓ years, but in a seemingly irregular pattern.
Making it useful
For any given year, you only need to know when you are relative to a leap year to work out when a calendar can be reused:
Year
Years until next reuse
Leap year
28
Year after leap year
6
Two years after leap year
11
Year before leap year
11
So if it is two years after a leap year, for example 2018, you can reuse your calendar 11 years later, in 2029.
If you want to calculate the next reuse after that, then the method is straightforward, but hard to explain clearly. First, I’ll provide a variation of the above table with just common years.
Year
Years until next reuse
Year after leap year
6
Two years after leap year
11
Year before leap year
11
Year after leap year
6
Two years after leap year
11
Year before leap year
11
Year after leap year
6
Two years after leap year
11
Year before leap year
11
Year after leap year
6
Two years after leap year
11
Year before leap year
11
To work out the reuse after the next reuse, step backwards through the table (wrapping round when you get to the beginning).
So, if it is 2019 (a year before a leap year), the next reuse is 11 years later in 2030. This is two years after a leap year, so the next reuse is found by reading the row above - 11 years later again in 2041. Now we are a year after a leap - repeating the process and reading the row above we find the next reuse is 6 years later in 2047.
This can be summarised in the following decision tree:
Taking it further
What we have so far will work for the vast majority of people, at least for working out calendars within your own lifetime. But if you want to work out years close to 2100, it will fail.
The reason is that the idea that a leap year is every four years is not the whole story. If the year is also divisible by 100, then it is not a leap year. So 2100 is not a leap year. And nether was 1900.
But… what about 2000? If you check a 2000 calendar you’ll find February 29th. Turns out there is another rule to leap years - if the year is also divisible by 400, it is a leap year. So 2000 was, and 2400 will be.
The reason these are added are to make up for the fact that the length of the year is not nicely divisible by the length of the day. There are currently no further rules but the day will drift again at some point.
There is a proposal to make every year divisible by 4000 into a common year but based on historical precedent we will probably completely change the calendar before that happens.
At first glance that table looks unhelpful - the numbers in the last column are all over the place. But, with a bit of careful thinking it’s only a small extension to the previous method.
The final algorithm
Any more issues
I have assumed two calendars are the same if they start on the same day and have the same number of days. But there are other differences, like when certain holidays occur.
Some of the holidays will change in the same way and so won’t matter. For example in the UK, Christmas Day is a bank holiday. If it happens to fall on a weekend, then the next weekday is a bank holiday in lieu.
Many holidays however do change, and it is mostly to do with the moon. For instance the definition of when Easter occurs in western Christianity is:
the first Sunday after the first full moon that falls on or after the vernal equinox
To make things a bit weirder, it’s not really the vernal equinox, but March 21 (the vernal equinox is often on March 21, but in reality happens some time between March 19 and March 22 and can vary with timezone). It’s also not the full moon in the astronomical sense, but the Paschal full moon, which is an approximation of the astronomical full moon based on the 19-year Metonic cycle. Full details here.
— This upcoming video may not be available to view yet.
I was doing an assignment for Cryptography last night and ended up stuck on a question for a really silly reason: I knew the answer straight away. All we had to do was decrypt the following cipher:
Which is all very well and good except that is possibly one of the most famous pieces of encrypted text there is. It’s froma story by Edgar Allan Poe. In fact a quick search on Google for 305))6*;4826)4 reveals 56,700 results. All but one of them on the first page are about the decrypting the damn thing.
So my problem is how do I write down my method? “Well I knew the first line began ‘a good glass in the bishop’s hostel’ and I worked from there”? Ack.
I need to go to the Post Office to buy envelopes. But there is a chance Julia might be online while I’m away. Hopefully isshe is she will read this and understand :o)
